Production-Ready System-on-Modules

Xilinx Zynq UltraSCALE+ MPSoC module

Xilinx Zynq MPSoC module with Quad ARM Cortex-A53 and 750k FPGA cells

Over 17 years,  we’ve helped hundreds of projects – maybe including one a little like yours – to get to market quickly and cost-effectively based on a production-ready module.

With a module, the OS porting and complex hardware design is already taken care of. You just need a simple custom baseboard and an application, and you’re done.

What type of module do I need?

An ARM-based module is usually the lowest-cost solution. Projects sometimes choose an x86 module because their platform must be full Windows, or PC-like in features. Other projects need an ARM+FPGA processor because of complex image processing, or motion control needs.

The tables below can help you to choose, and are linked to product pages. Even better, speak directly to one of our engineers. Expert support, in-stock development kits and a cost-effective range of solutions from the UK’s most experienced and largest module vendor are just a click or phone-call away.

 AT-501Spark-501TRITON TX28/STRITON TX6ULTRITON TX48TRITON TX6STRITON TX6DLTRITON TX6QTRITON TX6QPTRITON TXSDA31-uQ7A64-uQ7A80-Q7
ProcessorAtmel SAMA5D3Atmel SAMA5D3Freescale i.MX287/3Freescale i.MX6 UltraLiteTI Sitara AM335xFreescale i.MX6 SoloFreescale i.MX6 Dual LiteFreescale i.MX6 QuadFreescale i.MX6 Quad PlusQualcomm Snapdragon 410EAllwinner A31Allwinner A64Allwinner A80
CPUARM Cortex-A5ARM Cortex-A5ARM926EJ-SCortex-A7ARM Cortex-A8Cortex-A92x Cortex-A94x Cortex-A94x Cortex-A94x Cortex-A534x ARM Cortex-A74x ARM Cortex-A534x ARM Cortex-A15 4x ARM Cortex-A7
Clock Max (MHz)53653645452872080080010008001200120012001800
RAM (MB)256/512256/51264/128/256256256256/5121024102420481024512/1GB/2GB512/1GB/2GB2GB/8GB
NAND Flash (MB)256256/4GB128128/4GB128128/4GB128/4GB128/4GB4GB4GB4/16GB4/8/16GB4/16GB
Video Coprocessor-----yyyyyyyy
Graphics Engine----OpenGL ES 2.0/OpenVGOpenGL ES 2.0/OpenVGOpenGL ES 2.0/OpenVGOpenGL ES 2.0/OpenVGOpenGL ES 2.0/OpenVGOpenGL ES 3.0PowerVR SGX5Mali 400 MP2PowerVR Series6
Floating Pointyynyyyyyyyyyy
MAX UARTs 646/28655552111
Ethernet 100Mb/s1*12/1211111----
Gb Ethernet11*--1-----111
I2C Interface3312222222111
LCD Controller1280x7201280x720800×4801366x7681600x12001080p1080p1080p1080p1080p1080p601080p604K
Supplied LCD640x480*640x480*640 x 480*640 x 480*640 x 480*640 x 480*640 x 480*640 x 480*640 x 480*640 x 480*---
SSP (synch. serial / audio)1102-Jan2122222111
SD card3111222221111
1-Wire -----11111111
USB Host22111-----765
USB Client / OTG1111122221113
SPI2211222222111
PWM --15311111111
Keypad--4x4/ -4x44×48×88×88×88×85x4---
Camera Input1--1-22222--1
WiFi-y*bb*bb*bb*bb*bb*bb*bb1---
Bluetooth-y-------1---
CAN212 / -222222-111
PCIe-----1111----
SATA----------111
ADC125358--------
LVDS**---2*2*--1222
Temperature Range0 to 70C / -40 to +85C0 to 70C / -40 to +85C-40 to +85C / 0 to +70C-40 to +85C-40 to +85C-40 to +85C / -25 to +85C-40 to +85C / -25 to +85C-20 to +70C-40 to +85C-25 to +85C0 to 60C / -20 to 85C0 to 60C / -20 to 85C0 to 60C / -20 to 85C
Dimensions68 x 47mm82 x 50mm68 x 26mm68 x 26mm68 x 26mm68 x 31mm68 x 31mm68 x 31mm68 x 31mm68 x 26mm70 x 40mm70 x 40mm70 x 70mm
ConnectorsSODIMM200MXM314/ SMARCSODIMM200SODIMM200SODIMM200SODIMM200SODIMM200SODIMM200SODIMM200SODIMM200MXM230/ QSevenMXM230/ QSevenMXM230/ QSeven
Win 10 ioT CorennnnnnnnnTBAnnn
Compact 7yyyTBAyyyynnnnn
Compact 2013yynTBAnyyynnnnn
Linuxyyyyyyyyyyyyy
Androidnnnnnnnnny4.44.45
Windows 10nnnnnnnnnnnnn
AT-501Spark-501TRITON TX28/STRITON TX6ULTRITON TX48TRITON TX6STRITON TX6DLTRITON TX6QTRITON TX6QPTRITON TXSDA31-uQ7A64-uQ7A80-Q7
x86 processors have a reasonably standard set of connectivity. Therefore as well as system-on-modules we offer SBC and COMExpress Computer-on-modules.

 BTD-700BWD051ALD-700
TypeQseven modulePico-ITX SBCQseven module
Processor family4th Gen Atom Bay Trail E3800 series5th Gen Braswell x5-E8000, N3000 series6th Gen Atom Apollo Lake E3900 series
CPU SoCBay Trail x86x5-E8000, N3160, N3060, N3710Apollo Lake x86
Clock Max (MHz)up to 2.42GHzup to 2.56GHzup to 2.5GHz
RAM (MB)2GB/4GB onboardSODIMM to 8GB4GB/8GB onboard
NAND Flash (MB)up to 16GB-up to 16GB
Video Coprocessoryyy
Graphics EngineIntel HD GraphicsIntel HD Graphics 400Intel HD Graphics Gen9LP Series
LCD Controller1920x1200 x21920x1080 + 1366x7684092x2160, up to 3x
HDMI111
DP1-1
VGA-1-
LVDS212
MAX UARTs 121
Gb Ethernet111
I2C Interface111
SSP (synch. serial / audio)HDAHDAHDA
SD card111
USB Host72x 2.0, 2x 3.04x 2.0, 3x 3.0
CAN11
PCIe314
SATA21x SATA 3.02x SATA 3.0
Temperature Range0 to +60C / -25 to +85C / -40 to +85C0 to +60C 0 to +60C / -25 to +85C / -40 to +85C
Dimensions70 x 70mm100 x 72mm70 x 70mm
ConnectorsMXM230/ QSevenVarious SBCMXM230/ QSeven
Linuxyyy
Windows / WES7, 8, 107, 8, 1010 / IoT
BTD-700BWD051ALD-700
 Spark-100Spark-102Miami ZynqMiami Zynq MPSoCMiami Kintex
DeviceAltera SoCAltera SoCZynq XC7Z015/ 30Zynq UltraSCALE+Altera KC7K
FPGA Logic Cells (K)25/40/85/11025/40/85/11074/125469/600/747162/326/407
FPGA TypeCyclone VCyclone VArtix-7 / Kintex-7XCZU6EG, XCZU9EG, XCZU15EGKintex-7
Transceivers6x 3.1Gb/s*6x 3.1Gb/s*4x 6.6Gb/sPS-GTR 4x 6.0Gb/s4x 12.5Gb/s
CPU2x Cortex-A92x Cortex-A92x Cortex-A94x Cortex-A53softcore Microblaze
Clock Max (MHz)800/925800/925666/8001500250
RAM (MB)102410245121024512
NAND Flash (MB)4GB4GB256256128 (NOR)
Floating Pointyyyy-
MAX UARTs 24111
Ethernet 100Mb/s-EtherCAT, PROFINET---
Gb Ethernet11111
10Gb Ethernet----4
I2C Interface42111
SD card1111-
1-Wire -----
USB Host22--USB 3.0
USB Client / OTG11111
SPI-2111
CAN22222
PCIe4*4*114xGEN3
SATA**2SATA3SATA3
ADC--8811
LVDS**1DisplayPort1
Temperature Range0 to 50C / -40 to +85C0 to 70C / -40 to +85C-40 to +85C-40 to +85C-40 to +85C
Dimensions82 x 50mm82 x 50mm68 x 65mm68 x 65mm68 x 65mm
ConnectorsMXM314/ SMARCMXM314/ SMARC2 x 140 Samtec2 x 140 Samtec2 x 140 Samtec
Linuxyyyyy
Androidnnnnn
Spark-100Spark-102MiamiMiami Zynq MPSoCMiami Kintex
 PinoutTypeCoresGPUTempNotable Features
Family Features
Applications
TRITON TX28/S
pin-compatible SODIMM family
ARM91nCommercialv. low cost
10-15-year longevity, EU manufacture, broad range of price/performance in compatible family. Wide range of interfaces, secure boot, Yocto Linux + Qt. Windows CE available
Industrial, often with touch-screen display
TRITON TX6ULARM Cortex-A71nIndustrialv. low cost, low-power
TRITON TX6SARM Cortex-A91yIndustriallow cost with GPU
TRITON TX6DLARM Cortex-A92yIndustrialmid-range
TRITON TX6QARM Cortex-A94yCommercialhigh-performance
TRITON TX6QPARM Cortex-A94yIndustrialfast graphics, full industrial temp.
TRITON TXSDARM Cortex-A534yIndustrialoutstanding price/performance
AT-501SODIMMARM Cortex-A51nEitherWindows Compact 2013
Low cost, low power. IoT baseboard available with modem, 2.4GHz radio
low-cost industrial with Windows CE
Spark-501SMARCARM Cortex-A51nEitherLow-power, WiFi/BTIoT gateway, M2M wireless applications
A31-uQ7microQsevenARM Cortex-A74yEitherhigh-performance, low-cost
Ideal industrial Raspberry Pi replacement - . HDMI display
Linux PC, general industrial, higher volume applications
A64-uQ7microQsevenARM Cortex-A534yEitherhigh-performance, low-costLinux PC, general industrial, higher volume applications
A80-Q7QsevenARM Cortex-A158yEitherUltimate performancehigh-performance, DSP, video, large displays
Helix-2COMExpressARM Cortex 64bit4nIndustrial10GB Ethernet, 6x PCIe
High I/O throughput
Networking, storage, high-performance control
MiamiMiami FamilyFPGA + ARM Cortex-A92nIndustrialApprovals, quality, performance
Range of Kintex-7 FPGAs
Video, motion control, medical, transportation, space
Miami MPSoCFPGA + ARM Cortex-A534yIndustrialApprovals, quality, performance
Massive processing power
Video, motion control, medical imaging, HPC
Miami KintexFPGA + Softcore1nIndustrial10GB Ethernet, 4x PCIeHigh throughput datacomms. Video, DSP.
Spark-102SMARCFPGA + ARM Cortex-A91/2nEitherLow-cost, EtherCAT, PROFINET
Versatile, cost-effective FPGA SoC module
Video, real-time industrial control
BTD-700Qsevenx861/2/4yEitherLow-power
Full Windows application environment
general embedded PC, low power
BWD051Pico-ITX SBCx862/4yCommercialWindows, powerful graphics
embedded PC, video processing
ALD-700Qsevenx862/4yEitherup to 3 displays, Win 10 IoThigh performance multimedia PC
